INJET CHARGING STATIONS
Extend your adventure. The only charging solution your electric vehicle will ever need
Need to re-charge?
Compact and sturdy, specially designed for indoor and outdoor installation
With attractive ergonomic enclosure and user-friendly body design, the classical M3P wallbox charger is an intelligent, affordable and scalable charging solution.
INJET CHARGER
US SERIES
The various communication modules are convenient for different users to flexibly choose, tailored to the specific needs of the market segments.
Wi-Fi & 4G & LAN
Produced in strict accordance with UL regulations, each component performs excellent. Multiple listing negotiable.
UL Listed
RS-485 Interface Available
The charger is available for interact with Home Energy Management Systems via RS-485 interface.
POWERFUL AND HIGH SPEED
32A & 40A adjustable, enable high-speed home charging.
SIMPLE CHARGING
RFID cards & APP & Plug and play charging control,just choose what you like.
EASY INSTALLATION
Comes with NEMA 14-50P input plug. Full set of installation accessories.
100% COMPATIBLE
Fit for a11 EVs comply with SAE J1772 Type 1 standard.
RS-485 INTERFACE AVAILABLE
TYPE 4 electrical enclosure, works under all conditions. CCID 20.
SPECIFICATIONS
INJET 7 KW
M3P132U
10kW/40A
INJET 10 KW
M3P140U
7kW/32A
@Level 2 240VAC
@Level 2 240VAC
BASIC INFO
CONNECTOR
INPUT PLUG: NEMA 14-S0P; OUTPUT PLUG: TYPE 1/SAEJ1772
DIMENSIONS
310H X 220W X 95D
MATERIAL
PC
COLOR
WHITE FRONT + GREY BACK OR OEM COLOR
INDICATOR
4 LED LIGHTS (INDICATING 4 STATUSES: POWER, CHARGING, FAULT, AND NETWORK)
FEATURES
ETHERNET
YES
RFID
YES
WI-FI
2.4 GHz
4G
OPTIONAL
RS485
OPTIONAL
OCPP1.6J
OPTIONAL
APP
OPTIONAL
SAFETY
INGRESS PROTECTION
TYPE 4
RESIDUAL CURRENT PROTECTION
CCID 20
OVERLOAD PROTECTION
YES
OVER/UNDER VOLTAGE PROTECTION
YES
SHORT CIRCUIT PROTECTION
YES
EARTH LEAKAGE PROTECTION
YES
GROUND PROTECTION
YES
SURGE PROTECTION
YES
OVER TEMPERATURE
YES
CERTIFICATION
UL (FOR US AND CANADA), FCC, ENERGY STAR
CERTIFICATION STANDARD
UL 2594, CSA C22.2
ENVIRONMENT
INSTALLATION
WALL/POLE MOUNTED
STORAGE TEMPERATURE
-40~75°C
WORK TEMPERATURE
-30~55°C
WORK HUMIDITY
≤ 95%RH, NO WATER DROPLET CONDENSATION
WORK ALTITUDE
< 2000M
ORDER YOUR NEW INJET CHARGER NOW
